Parked Car Finder

Using a Linkit One, I send GPS data to my phone so I never forget where I parked my car!

EasyFull instructions provided808
Parked Car Finder

Things used in this project

Hardware components

LinkIt ONE
MediaTek Labs LinkIt ONE
×1
Android device
Android device
×1

Story

Read more

Schematics

Linkit One Connections

You only need the Linkit One, Bluetooth antenna, GPS antenna and Battery (all of which came with the Linkit One box)
800px linkitone resource

Code

BluetoothWithGPS

Arduino
The code I use to get the Linkit One to send me information. It relies on a couple of libraries (that come when you setup the Linkit One)
// Libraries that I use
#include <LGPS.h>
#include <LBT.h>
#include <LBTServer.h>

// Create the GPS sentence structure for the GPS component
gpsSentenceInfoStruct info;

// Create the buff variable for the bluetooth component
char buff[256];

// getComma is from the GPS example to seperate the GPS string
static unsigned char getComma(unsigned char num,const char *str)
{
  unsigned char i,j = 0;
  int len=strlen(str);
  for(i = 0;i < len;i ++)
  {
     if(str[i] == ',')
      j++;
     if(j == num)
      return i + 1;
  }
  return 0;
}

// getDoubleNumber is from the GPS example to convert the string to a number
static double getDoubleNumber(const char *s)
{
  char buf[10];
  unsigned char i;
  double rev;

  i=getComma(1, s);
  i = i - 1;
  strncpy(buf, s, i);
  buf[i] = 0;
  rev=atof(buf);
  return rev;
}

// getIntNumber is from the GPS example to convert the string to a number
static double getIntNumber(const char *s)
{
  char buf[10];
  unsigned char i;
  double rev;

  i=getComma(1, s);
  i = i - 1;
  strncpy(buf, s, i);
  buf[i] = 0;
  rev=atoi(buf);
  return rev;
}

// I start my setup section
void setup() {
  // I setup my baud rate at 9600
  Serial.begin(9600);
  // I turn on the GPS section of the Linkit One
  LGPS.powerOn();
  // Tell the serial port that it is on.
  Serial.println("LGPS Power on, and waiting ...");

  delay(3000);

  // I startup the bluetooth component and tell the serial port it's working
  if(!LBTServer.begin((uint8_t*)"My_BTServer"))
  {
    Serial.println("Fail to start BT.");
    return;
  }
    Serial.println("BT server is started.");
}


void loop() {
  // put your main code here, to run repeatedly:
  Serial.println("LGPS loop");
  // I grab the GPS data
  LGPS.getData(&info);
  // I set the variable GPGGAstr to be the info
  const char* GPGGAstr = (const char*)info.GPGGA;

  // I create the variable lat and lon (to get the all the digits)
  double lat = 0;
  double lon = 0;
  // I create the variables latitude and longitude to convert lat and lon
  // and use those string values
  String latitude;
  String longitude;

  // buf and bytesRead is used for the bluetooth portion
  uint8_t buf[64];
  int bytesRead;

  int tmp;


  // If something connects to the Linkit One via bluetooth then I can start
  // sending information to the phone
  if(LBTServer.connected())
  {
      // if the start of the GPS string is a $ sign then I know that I grabbed
      // it correctly
      if(GPGGAstr[0] == '$')
      {
        // I set the temporary variable to be the latitude section
        tmp = getComma(2, GPGGAstr);
        // I use the getDoubleNumber to convert that string to a double
        lat = getDoubleNumber(&GPGGAstr[tmp]);
        // I set the temporary variable to be the longitude section
        tmp = getComma(4, GPGGAstr);
        // I use the getDoubleNumber to convert that string to a double
        lon = getDoubleNumber(&GPGGAstr[tmp]);

        // I don't need these after I verify it. The String() function
        // can be used to specify the number of digits (in this case 6)
        //Serial.println(String(lat/100,6));
        //Serial.println(String(lon/100,6));

        // I set the latitude to have 6 digits in the decimal place and
        // at a comma at the end so I can interpret it correctly
        latitude = String(lat/100,6) + ',';
        // I set the longitude to have 6 digits in the decimal place
        // and add a negative sign at the beginning (because the GPS
        // coordinate doesn't have the negative sign built in
        longitude = '-' + String(lon/100,6);


        // I set strlen1 to be the size of the latitude string +1
        int strlen1 = latitude.length() + 1;
        // I set strlen2 to be the size of the longitude string +1
        int strlen2 = longitude.length() + 1;
        // I use bufspot for bytesRead portion (bytesRead is the verification
        // that the transmission sent correctly)
        int bufspot = 0;
        // I create two arrays to fill in the buf array
        char chararray1[strlen1];
        char chararray2[strlen2];
        // I use the function toCharArray() to fill in the two arrays I just
        // created.
        latitude.toCharArray(chararray1,strlen1);
        longitude.toCharArray(chararray2,strlen2);

        // I create the variable i so that I can use it for the for loop
        int i;

      // I start filling out the buf array for the bluetooth transmission
      // I increase the variable bufspot each time I loop
      for (i = 0; i<strlen1; i++) {
        buf[i] = chararray1[i];
        bufspot++;
      }

      // I set the variable buf2 to the value of bufspot
      int buf2 = bufspot;

      // I iterate from bufspot to bufspot+strlen2 and I fill
      // out the buf array with the remaining information. I
      // increase buf2 each time (which will be used to set
      // bytesRead to)
      for (i = bufspot; i < bufspot+strlen2; i++) {
        buf[i] = chararray2[i-bufspot];
        buf2++;
      }

      // The last index of the buf array has to be 0 so that the
      // transmission knows when to end
      buf[buf2+1] = 0;
      // I set bytesRead to buf2
      bytesRead = buf2;

      // This is an example of what the individual arrays look like
      //buf[0] = 'a';
      //buf[1] = 'b';
      //buf[2] = 'c';
      //buf[3] = 0;
      //bytesRead = 4;

      // I write the the serial port so that you can see what's going
      // to be transmitted
      Serial.write(buf, bytesRead);
      // Then I start to transmit to the Server (in this case my phone)
      // the same thing I sent to the Serial port
      LBTServer.write(buf, bytesRead);

      // This is all mostly unneccessary because this is the portion where
      // I read back the transmissions from the phone but I will explain it
      // anyway

      // while(true) indicates whether or not I've correctly sent the information
      // to the device
      while(true)
      {
        // I set bytesRead to be whatever buf is at the moment (basically
        // grabbing the transmission)
        bytesRead = LBTServer.readBytes(buf, 64);

            // I print back what I read to the Serial port
            Serial.println(bytesRead);

            // if I listen to it wrong then I want to break this code and
            // move on
            if(!bytesRead)
            break;

        // If the first letter that I read in is a capital S then I'm going
        // to set the buf array with abc
        if (buf[0] == 'S') {
            buf[0] = 'a';
            buf[1] = 'b';
            buf[2] = 'c';
            buf[3] = 0;
            bytesRead = 4;
            // I'm then going to write to the serial port what I just put
            // together
            Serial.write(buf, bytesRead);
            // And then I'm going to send it to the bluetooth connected
            // device (in this case my phone)
            LBTServer.write(buf, bytesRead);
        }

      } // end of the while(true) portion

        // I wait 2 seconds before I can continue looping
        delay(2000);

    }
      // If it doesn't have a $ sign at the beginning then the GPS is not setup
      // correctly
      else
      {
        // I print out that it didn't get received correctly
        Serial.println("Not get data");
      }

  } // end of the if(LBTServer.connected()) section

  // If the bluetooth is not connected then I want to wait and listen
  // for another connection. If I get one then I will be connected
  else
  {
    LBTServer.accept(5);
  }

} // end of loop() section

GPS example

Arduino
This is the one that comes when you setup the Linkit One files.
#include <LGPS.h>

gpsSentenceInfoStruct info;
char buff[256];

static unsigned char getComma(unsigned char num,const char *str)
{
  unsigned char i,j = 0;
  int len=strlen(str);
  for(i = 0;i < len;i ++)
  {
     if(str[i] == ',')
      j++;
     if(j == num)
      return i + 1;
  }
  return 0;
}

static double getDoubleNumber(const char *s)
{
  char buf[10];
  unsigned char i;
  double rev;

  i=getComma(1, s);
  i = i - 1;
  strncpy(buf, s, i);
  buf[i] = 0;
  rev=atof(buf);
  return rev;
}

static double getIntNumber(const char *s)
{
  char buf[10];
  unsigned char i;
  double rev;

  i=getComma(1, s);
  i = i - 1;
  strncpy(buf, s, i);
  buf[i] = 0;
  rev=atoi(buf);
  return rev;
}

void parseGPGGA(const char* GPGGAstr)
{
  /* Refer to http://www.gpsinformation.org/dale/nmea.htm#GGA
   * Sample data: $GPGGA,123519,4807.038,N,01131.000,E,1,08,0.9,545.4,M,46.9,M,,*47
   * Where:
   *  GGA          Global Positioning System Fix Data
   *  123519       Fix taken at 12:35:19 UTC
   *  4807.038,N   Latitude 48 deg 07.038' N
   *  01131.000,E  Longitude 11 deg 31.000' E
   *  1            Fix quality: 0 = invalid
   *                            1 = GPS fix (SPS)
   *                            2 = DGPS fix
   *                            3 = PPS fix
   *                            4 = Real Time Kinematic
   *                            5 = Float RTK
   *                            6 = estimated (dead reckoning) (2.3 feature)
   *                            7 = Manual input mode
   *                            8 = Simulation mode
   *  08           Number of satellites being tracked
   *  0.9          Horizontal dilution of position
   *  545.4,M      Altitude, Meters, above mean sea level
   *  46.9,M       Height of geoid (mean sea level) above WGS84
   *                   ellipsoid
   *  (empty field) time in seconds since last DGPS update
   *  (empty field) DGPS station ID number
   *  *47          the checksum data, always begins with *
   */
  double latitude;
  double longitude;
  int tmp, hour, minute, second, num ;
  if(GPGGAstr[0] == '$')
  {
    tmp = getComma(1, GPGGAstr);
    hour     = (GPGGAstr[tmp + 0] - '0') * 10 + (GPGGAstr[tmp + 1] - '0');
    minute   = (GPGGAstr[tmp + 2] - '0') * 10 + (GPGGAstr[tmp + 3] - '0');
    second    = (GPGGAstr[tmp + 4] - '0') * 10 + (GPGGAstr[tmp + 5] - '0');

    sprintf(buff, "UTC timer %2d-%2d-%2d", hour, minute, second);
    Serial.println(buff);

    tmp = getComma(2, GPGGAstr);
    latitude = getDoubleNumber(&GPGGAstr[tmp]);
    tmp = getComma(4, GPGGAstr);
    longitude = getDoubleNumber(&GPGGAstr[tmp]);
    sprintf(buff, "latitude = %10.4f, longitude = %10.4f", latitude, longitude);
    Serial.println(buff);

    tmp = getComma(7, GPGGAstr);
    num = getIntNumber(&GPGGAstr[tmp]);
    sprintf(buff, "satellites number = %d", num);
    Serial.println(buff);
  }
  else
  {
    Serial.println("Not get data");
  }
}

void setup() {
  // put your setup code here, to run once:
  Serial.begin(115200);
  LGPS.powerOn();
  Serial.println("LGPS Power on, and waiting ...");
  delay(3000);
}

void loop() {
  // put your main code here, to run repeatedly:
  Serial.println("LGPS loop");
  LGPS.getData(&info);
  Serial.println((char*)info.GPGGA);
  parseGPGGA((const char*)info.GPGGA);
  delay(2000);
}
